SMART REEL COUNTER
SMART X-RAY REEL COUNTER-TECHVALLEY-HAWKEYE 2000
Smart Reel Counter Features:
- Simple and easy Operation
- Count Accuracy > 99.9%
- Fast in Counting
- MES / ERP Integration
- Automatic Barcode Scanner (Option)
The Inventor of Chip counter now provides the advanced new machine to the world called HAWKEYE 2000
-
User friendly GUI : HAWKEYE2000’s GUI consists of intuitive graphics and operational procedure for less training and fast usage
-
Easy counting error fix : Techvalley system starts a deep learning process by advanced AI technology by user’s one button clicking
-
Poka – yoke : Functions for human error reduction provided – Black and white list, manual Q’ty adjustment, automatic barcode scanner etc.
-
Real-time radiation protection : External radiation leakage detector Techvalley patented will protect user fully from danger of exposure
-
SMART FACTORY (Industry 4.0) : Compliant fully based on experience with many customers all over the world
-
Devoted C/S : Techvalley takes care of customers’ issues as first priority and provide prompt service for better productivity and efficiency
Specification
| Machine | HAWKEYE2000 |
| X-Ray Source |
55kV / 110W / 400µm Focal spot size |
| Image Detection |
17 inches FPXD / 140µm Pixel size |
| Inspection Area |
Max. 380mm Reel / Min. 180mm Reel / Min. 0201 Chip |
| X-Ray Safety | 1uSv / a hour |
|
Dimension & Weight (W X D X H / mm) |
900 X 1,316 X 1,930 / 650kg |
| Manipulator | Feeding door type |
